Defining grid structure on server-side
- client-side
- server-side

Defining grid structure on server-side

client-side

index.html

<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
<head>
    <script src="codebase/dhtmlx.js" type="text/javascript"></script>
    <script src="codebase/connector/connector.js"></script>
    <link rel="STYLESHEET" type="text/css" href="codebase/dhtmlx.css">
    <div id="gridbox" style="width:350px;height:250px";border:1px solid #A4BED4;></div>

    <script type="text/javascript">

     function doOnLoad(){
         var mygrid = new dhtmlXGridObject('gridbox');
         mygrid.setImagePath("codebase/imgs/");
         mygrid.setSkin("dhx_skyblue");
         mygrid.load("griddata.php");
     }
    </script>
</head>
<body onload="doOnLoad()">
</body>
</html>

server-side

griddata.php

<?php
require_once("../codebase/connector/grid_config.php");
require_once("../codebase/connector/grid_connector.php");

$res=mysql_connect("localhost","root","");
mysql_select_db("tasks");
$conn = new GridConnector($res);
        $config = new GridConfiguration();

	$config->setHeader("Item Name,Item CD");
	$config->attachHeader("Item Name Test,#rspan");
	$config->attachFooter("Item Name,Item CD", Array("background: #ff0000;", "background: #00ff00;"));
	$config->attachFooter("Item Name Test,#rspan", "background: #0000ff;color:white;");
	$config->setColIds("col1,col2");
	$config->setInitWidths('120,*');
	$config->setColSorting("connector,connector");
	$config->setColColor("null,#dddddd");
	$config->setColHidden("false,false");
	$config->setColTypes("ro,ed");
	$config->setColAlign('center,center');

$conn->set_config($config);
$conn->render_table("grid50000","id","item_nm,item_cd");

?>
